Overview & Creative Tools

Groove Circuit (rekordbox on Mac/Windows)

Enables live remixing of drum elements. You can swap a track’s drum parts—even mid-play—with different loops, apply effects like rolls, fills, build-ups, and breakdowns, or extract (“capture”) drum parts to drop into another track. A free reggae-style drum loop pack (40 loops) is available for experimentation.

Stems FX (Serato DJ Pro)

In Serato mode, the Groove Circuit transforms into Stems FX—letting you isolate stems like drums, bass, vocals, or melody, and apply effects such as Roll, Trans, Echo Out, and Delay, achieving deeply creative track manipulation.

2. Design & Layout

Club-Style Gear Feel

Inspired by flagship equipment, it includes large jog wheels (ideal for scratching), 8 performance pads per deck positioned above the jogs (like those on CDJ‑3000 players), and Beat FX knobs borrowed from DJM‑A9 mixers.

Smart Rotary Selector

A multifunctional knob (tilt, rotate, push) that enables fast navigation through track libraries. Left/right tilts enable browser navigation, while up/down tilts navigate playlists.

Discover Feature

A single button press to trigger Track Suggestions in rekordbox, helping rediscover old favorites or find new tracks quickly.

3. Device and Software Support

Wide Compatibility

Fully compatible with rekordbox (Mac, Windows, iOS, Android), Serato DJ Pro, and Algoriddim’s djay Pro suite (on Mac/Windows/iOS), including support for Neural Mix and streaming via Apple Music in djay.

Mobile Use

When using rekordbox mobile (iOS/Android), only channels 1 & 2 are accessible. Djay requires a paid subscription. Bluetooth is not supported.

USB-C Audio Output

Allows audio direct output from iPhone/iPad via USB‑C, enabling DJing without external speakers when using mobile devices.

4. Audio, Connectivity & Build

Professional Inputs & Outputs

Includes a built-in sound card, dual USB‑C ports (host + power), mic input (¼″ TRS), master outputs (¼″ TRS + RCA), booth output (RCA), and dual headphone jacks (¼″ & 3.5 mm).

Audio Quality

Offers 20 Hz–20 kHz frequency response, 104 dB S/N ratio, and 0.003% total harmonic distortion via USB.

Power Options

Can be powered via USB bus (5 V, 1.5 A) or an external adapter (9 V, 3 A). External power is needed when using mobile devices.

Class-Compliant & Firmware Updates

Plug-and-play with computers—no driver needed. Firmware updates are managed through AlphaTheta Care.

5. Specifications & Physical Attributes

Dimensions & Weight

Approximately 28.0″ × 14.8″ × 3.0″ (711.4 × 375.9 × 75.7 mm), weighing around 10.2 lbs (4.6 kg).

Performance Controls

4 internal channels (mixer) with 4/deck mode switching

206 mm jog wheels

8 hot cues per deck

Samplers: rekordbox (16 slots × 4 banks), Serato (8 slots × 4 banks)

Pad modes:

rekordbox: Hot Cue, Stems, Beat Jump, Sampler, Keyboard, Pad FX, Beat Loop, Key Shift

Serato: Hot Cue, Stems, Beat Jump, Sampler, Pitch Play, Pad FX, Auto Loop, Key Shift

Accessories Included

Depending on the region, the package includes a USB‑C cable, overlay sheet for Stems FX, Quick Start guide, and warranty documentation.

6. Design & User Experience

Sleek & Ergonomic Design

The controller’s matte black finish, minimalistic interface, and thoughtful layout (with Groove Circuit area elevated above pads) minimize accidental button contact and ease navigation.

Professional Layout Feel

Seamlessly mirrors CDJ‑3000 and DJM‑A9 equipment, making it familiar and comfortable for DJs used to club systems.

7. Summary Table

Feature

Description

Creative Tools

Groove Circuit (rekordbox) + Stems FX (Serato)

Layout

Jog wheels, performance pads, Beat FX—club style

Navigation Tools

Smart Rotary Selector + Discover button

Compatibility

rekordbox (desktop/mobile), Serato DJ Pro, djay Pro

Connectivity

USB‑C, mic input, master/booth outputs, dual headphone jacks

Audio Specs

20 Hz–20 kHz, 104 dB SNR, 0.003% THD

USB‑bus or 9 V adapter

Physical Specs

~28 × 14.8 × 3 in, ~10.2 lbs

Extras

Overlay, cable, guide, firmware support, warranty
