A featherweight champion in the world of outboard engines. At only 29 pounds, this makes it an optimal choice for small crafts, including square stern canoes, small tenders and inflatables, and even kayaks. The model comes equipped with a twist grip throttle for full-size control, forward-neutral gear shift, and a comprehensive 360° steering mechanism. For ease of transportation, it’s designed with integrated carrying handles. An integral fuel tank is included, making it a versatile choice for the 15 inch short shaft.

Specifications

Model

DF2.5 S5

Weight

29.0 lb

Manufacturer

Suzuki

Country of Manufacture

Thailand

Horsepower

2.5 HP

Shaft Length

15″ (Short)

Steering

Tiller

Starting

Manual

Trim & Tilt

Fuel Delivery

Carburetor

Fuel Tank

Internal

Cylinder(s)

1

Displacement

68 CC

Bore and Stroke

48 mm x 38 mm

RPM Range

5250

Ignition System

Digital Capacitor Discharge Ignition System

Induction Scavenging

OHV

Valves per Cylinder

2

Fuel Type

Unleaded Gasoline (87 octane)

Oil Type

SAE 10W-30 or SAE 10W-40

Oil Capacity

10

Lubrication

0

Alternator

Cooling System

Water-Cooled

Saltwater Rated

Yes

Gear Ratio

2.15:1

Gear Shift

Forward-Neutral w/ 360° Steering for Reverse

Propeller

3 blade aluminum 7.5″ Dia. x 5.5″ Pitch

Internal Battery

No

Features

Compact and Lightweight Design

Multi-Layer Corrosion Protection

Quiet Below-the-Water Exhaust

Fold-Down Tiller Handle

Twist-Grip Throttle with Tensioner

Large Carrying Handle

Suzuki PEI Pointless Electronic Ignition

3-Star Ultra-Low Emission Rating

Shallow Water Drive

Over-Rev Limiter Protection

Compression Reduction Starting System

Steering Friction Tension Control

Emergency Lanyard Stop Switch

Built-in .26 Gal. Fuel Tank (45 min. @ WOT)

3-Blade Aluminum Propeller

Suzuki’s Newest 5-Year Manufacturer Warranty
